| serial number | brand | item_title | item# | mfg# |
|---|---|---|---|---|
| 1 | S.R. Smith | 24 V Motor | 120-1100 | |
| 2 | SR Smith Lift Operator, 4 Button, Replacement Kit (Battery Not Included) | 400-7000 | SSR4007000 | 400-7000 | |
| 3 | S.R. Smith | Battery Pack | 1001495 | |
| 5 | S.R. Smith | Small Spur Gear, Plated | 800-5065 | |
| 6 | S.R. Smith | SR Smith LA34 Actuator for Splash Lift | 100-5000A | SSR1005000A | 1005000A |
| 8 | S.R. Smith | Motor Assembly, Complete | 120-1000 | |
| 9 | S.R. Smith | Hub Assembly | 130-1000 | |
| 10 | S.R. Smith | Mast Assembly | 150-1100A | |
| 11 | S.R. Smith | Seat Arm | 150-1400 | |
| 12 | S.R. Smith | Seat Assembly | 160-8000A | |
| 13 | S.R. Smith | SR SMITH FOOT REST W/HARDWARE - GRAY PLS (.145) | SSR1602300A | 160-2300A |
| 14 | S.R. Smith | PAL Main Frame Assembly | 200-1000 | |
| 15 | S.R. Smith | Rigid Caster | 200-2000 | |
| 16 | S.R. Smith | Swivel Caster | 200-3000 | |
| 17 | S.R. Smith | Cast Iron Weight Plates | 110-3100 | |
| 18 | S.R. Smith | PAL Housing Assembly | 200-5000 | |
| 19 | S.R. Smith | Stabilizer Assembly | 200-4100 | |
| 20 | S.R. Smith | Seat Belt Assembly | 900-1000 | SSR9001000 | 9001000 |
| 21 | S.R. Smith | Motor Plate | 120-1200 | |
| 22 | S.R. Smith | 1/4" Lock Washer S/S | 5-149 | |
| 23 | S.R. Smith | 6mm x 1 x 20mm Long Cap Screw | 800-2025 | |
| 24 | S.R. Smith | 3/8" Nylon Washer | 05-32-111 | |
| 25 | S.R. Smith | 10mm Push Retainer | 800-2064 | |
| S.R. Smith | Sr Smith Charger For Lift-Operator | 1001530 | SSR1001530 | 1001530 | |
| S.R. Smith | Console Cover (optional accessory, not shown) | 910-1000T |
