Eminence H2EA 2" Cast Aluminum Exponential Horn 60x40 4-Bolt
Brand Eminence Speaker
Shop more from PEX
* Click "Add to Cart" to calculate shipping and delivery time.
Pricing Note
Product Description
Manufacturer Part Number: H2EA
Cast aluminum construction and skilled use of finite element analysis ensure the Eminence H2EA 2" exponential horn delivers reliable, tightly controlled sound reproduction in portable and permanent applications.
Key Features:
Overview:
Eminence H2EA 2" Cast Aluminum Exponential Horn 60x40 4-Bolt
The Eminence H2EA 60° x 40° 2" horn features durable cast aluminum construction and an exponential flare geometry that optimizes acoustical loading and high frequency efficiency. Although its mouth area requires minimal baffle space, the H2EA horn operates down to 700 Hz and provides excellent functionality when deployed in venues of any size. A 60° x 40° dispersion pattern maintains maximum directivity and gain, keeping the horn's coverage well-controlled and focused.
In addition to the aluminum horn body's high mechanical strength, its ability to couple to high frequency drivers thermally results in a measured 25°F reduction in operating temperature. The utility of this heat sink advantage is especially obvious when using neodymium drivers, and results in improved reliability and reduced power compression.
Thanks to extensive FEA-optimized testing, as well as extensive listening evaluations, the Eminence H2EA reproduces its intended frequency range without coloration, diffraction effects, or distortion. Recommended for pro audio multi-way loudspeakers, stage monitors, and high output cinema systems.
Specifications: Horn type: Exponential Minimum frequency: 700 Hz Nominal dispersion: 60° H x 40° V Throat diameter: 2" Mounting type: 4-bolt Dimensions: 12.4" W x 7.3" H x 6.1" D Cutout dimensions: 11.3" x 6.3" Weight 4.9 lbs.
Specification:
Manuals & Resources:
Cast aluminum construction and skilled use of finite element analysis ensure the Eminence H2EA 2" exponential horn delivers reliable, tightly controlled sound reproduction in portable and permanent applications.
Key Features:
- FEA-optimized aluminum design is durable and hi-fi sounding
- High gain design is ideal for long throw applications
- Tightly controlled directivity reduces destructive interactions between adjacent loudspeakers
- Heat sink property provides additional cooling to hardworking high frequency drivers
- Industry standard 2" throat, 4-bolt mounting for large format HF drivers
Overview:
Eminence H2EA 2" Cast Aluminum Exponential Horn 60x40 4-Bolt
The Eminence H2EA 60° x 40° 2" horn features durable cast aluminum construction and an exponential flare geometry that optimizes acoustical loading and high frequency efficiency. Although its mouth area requires minimal baffle space, the H2EA horn operates down to 700 Hz and provides excellent functionality when deployed in venues of any size. A 60° x 40° dispersion pattern maintains maximum directivity and gain, keeping the horn's coverage well-controlled and focused.
In addition to the aluminum horn body's high mechanical strength, its ability to couple to high frequency drivers thermally results in a measured 25°F reduction in operating temperature. The utility of this heat sink advantage is especially obvious when using neodymium drivers, and results in improved reliability and reduced power compression.
Thanks to extensive FEA-optimized testing, as well as extensive listening evaluations, the Eminence H2EA reproduces its intended frequency range without coloration, diffraction effects, or distortion. Recommended for pro audio multi-way loudspeakers, stage monitors, and high output cinema systems.
Specifications: Horn type: Exponential Minimum frequency: 700 Hz Nominal dispersion: 60° H x 40° V Throat diameter: 2" Mounting type: 4-bolt Dimensions: 12.4" W x 7.3" H x 6.1" D Cutout dimensions: 11.3" x 6.3" Weight 4.9 lbs.
Specification:
Product Details | |
|---|---|
| Brand | Eminence Speaker |
| Model | H2EA |
| Part Number | 290-551 |
| UPC | 876358000487 |
| Unit of Measure | Each |
| Weight | 4.55 |
Product Specifications | |
|---|---|
| Construction | Aluminum |
| Entry / Throat Diameter | 2" |
| Mounting Type | 4-Bolt |
Manuals & Resources:
